Computer Network Quick Version

Base#

TCP/IP Network Model#

Application Layer: Responsible for providing a set of applications to users.

HTTP, FTP, Telnet, DNS, SMTP, etc. The application layer operates in user mode.
Transport Layer: Responsible for end-to-end communication.

TCP: flow control, timeout retransmission, congestion control, etc. / UDP

MSS (Maximum Segment Size) -> TCP Segment
Network Layer: Responsible for encapsulation, fragmentation, routing, and forwarding of network packets.

IP Protocol: addressing, routing. / ICMP

MTU (Maximum Transmission Unit) -> Fragmentation
Link Layer: Responsible for the transmission of network packets in the physical network, such as framing network packets, MAC addressing, error detection, and transmitting network frames through network cards, etc. / ARP

OSI Seven-Layer Network Model#

Application Layer, responsible for providing a unified interface for applications;
Presentation Layer, responsible for converting data into a format compatible with another system;
Session Layer, responsible for establishing, managing, and terminating communication sessions between presentation layer entities;
Transport Layer, responsible for end-to-end data transmission;
Network Layer, responsible for routing, forwarding, and fragmentation of data;
Data Link Layer, responsible for framing data and error detection, as well as MAC addressing;
Physical Layer, responsible for transmitting data frames in the physical network;

From URL to Web Page Display#

Parse URL -> web server and file name
Generate HTTP request
DNS domain name resolution
TCP three-way handshake to establish connection
TCP packet generation
IP packet generation -> IP address responsible for remote location
MAC packet generation (using ARP to query MAC address) -> MAC address responsible for point-to-point transmission
Network card, adds header and start frame delimiter at the beginning, adds frame check sequence (FCS) for error detection at the end, digital information -> electrical signal
Switch (Layer 2 network device), checks the switch's MAC address table (MAC-port), if not found, forwards to all ports
Router (Layer 3 network device), checks the routing table for IP (route matching), ARP checks MAC.
Arrives at the server, parses the data packet, sends HTTP response
Client receives HTTP response, renders the page
TCP four-way handshake to disconnect

During the forwarding process, the source IP address and destination IP address remain unchanged, while the source MAC and destination MAC change.

Overall, it can be divided into the following steps:

Enter the specified web page URL in the browser.
The browser obtains the corresponding IP address of the domain name through the DNS protocol.
The browser initiates a TCP connection request to the target server based on the IP address and port number.
The browser sends an HTTP request message to the server over the TCP connection, requesting the content of the web page.
After receiving the HTTP request message, the server processes the request and returns the HTTP response message to the browser.
After the browser receives the HTTP response message, it parses the HTML code in the response body, renders the structure and style of the web page, and simultaneously initiates HTTP requests again to obtain the content of other resources in the HTML (such as images, CSS, JS, etc.) until the web page is fully loaded and displayed.
When the browser does not need to communicate with the server, it can actively close the TCP connection or wait for the server's close request.

HTTP_Interview#

HTTP is the Hypertext Transfer Protocol.

What is a Protocol#

A protocol defines the format and order of messages exchanged between two or more communication entities, as well as the actions taken when sending and/or receiving a message or other events.

It establishes a specification for communication between computers using a language that computers can understand (involving two or more participants), along with various controls and error handling methods (behavior agreements and specifications).

HTTP Status Codes#

1xx: Indicates an informational response
- 101 indicates switching protocols, commonly seen in WebSocket connections;
2xx: Indicates a successful response
- "200 OK" indicates success
- "204 No Content" indicates the response has no body data
- "206 Partial Content" indicates only part of the content was sent;
3xx: Indicates a redirection response
- "301 Moved Permanently" indicates permanent redirection
- "302 Found" indicates temporary redirection
- 303 indicates the client should resend the request along the specified path
- "304 Not Modified" indicates the resource has not been modified, redirecting to the cache (cache redirection);
4xx: Indicates an error response due to client issues
- "400 Bad Request" indicates an error in the client's request message
- "403 Forbidden" indicates the server forbids access to the resource
- "404 Not Found" indicates the specified path does not exist;
5xx: Indicates an error response due to server issues:
- "500 Internal Server Error" indicates an internal server failure
- "501 Not Implemented" indicates the requested functionality is not supported
- "502 Bad Gateway" indicates the server is functioning normally, but an error occurred when accessing the backend server
- "503 Service Unavailable" indicates the server is busy and temporarily unable to respond.

Common HTTP Fields#

The format of an HTTP request is fixed, consisting of HTTP Header and HTTP Body. The first line is always request method path HTTP version, for example, GET / HTTP/1.1 indicates a GET request, the path is /, and the version is HTTP/1.1.

Each subsequent line follows the fixed Header: Value format, referred to as HTTP Header. The server relies on specific headers to identify client requests, such as:

Host: Indicates the requested domain name; since a single server may host multiple websites, it is necessary to rely on Host to identify which website the request is for;
User-Agent: Indicates the client's identification information; different browsers have different identifiers, and the server uses User-Agent to determine whether the client is IE, Chrome, Firefox, or a Python crawler;
Accept: Indicates the HTTP response formats the client can handle; */* indicates any format, text/* indicates any text, image/png indicates PNG format images;
Accept-Language: Indicates the languages accepted by the client, with multiple languages prioritized; the server uses this field to return a specific language version of the webpage to the user.

If it is a GET request, then the HTTP request only has HTTP Header, without HTTP Body. If it is a POST request, then the HTTP request includes a Body, separated by an empty line.

POST requests typically set Content-Type to indicate the type of the Body and Content-Length to indicate the length of the Body, allowing the server to respond correctly based on the request's Header and Body.

HTTP responses also consist of Header and Body. The first line of the response is always HTTP version response code response description, for example, HTTP/1.1 200 OK indicates the version is HTTP/1.1, the response code is 200, and the response description is OK. The client relies solely on the response code to determine whether the HTTP response was successful. HTTP has fixed response codes.

The HTTP protocol uses carriage return and line feed as boundaries for HTTP headers, and the Content-Length field as the boundary for the HTTP body; both methods are designed to solve the "sticky packet" problem.

Other fields:

Connection: Most commonly used for the client to request the server to use the "HTTP persistent connection" mechanism for request reuse.
Content-Encoding: Indicates the method of data compression. It specifies the compression format used for the data returned by the server.

GET vs POST#

The semantics of GET is to retrieve the specified resource from the server. The parameters of a GET request are generally written in the URL, which only supports ASCII characters, so GET request parameters are limited to ASCII characters, and browsers impose a limit on the length of URLs (the HTTP protocol itself does not specify any limit on URL length).

The semantics of POST is to process the specified resource based on the request payload (message body). The data for POST requests is generally written in the message body, and the data in the body can be of any format as long as the client and server agree, and browsers do not impose size limits on the body.

In the HTTP protocol, "safe" means that the request method does not "destroy" resources on the server.
"Idempotent" means that executing the same operation multiple times yields the "same" result.

Thus, the GET method is safe and idempotent because it is a "read-only" operation and can be cached; the POST method is neither safe nor idempotent because it modifies resources on the server and is mostly not cacheable.

HTTP Caching#

Strong caching: As long as the browser determines that the cache has not expired, it directly uses the browser's local cache, with the initiative to decide whether to use the cache resting with the browser.

Cache-Control, is a relative time;
Expires, is an absolute time;

Negotiated caching: After negotiating with the server, the result of the negotiation determines whether to use the local cache. HTTP 200 OK / HTTP 304

Implemented based on unique identifiers: response header Etag (unique identifier for the response resource) and request header If-None-Match;
Implemented based on time: response header Last-Modified and request header If-Modified-Since;

Note that both fields for negotiated caching need to be used in conjunction with the Cache-Control field in strong caching; requests with negotiated caching fields can only be initiated when strong caching fails to hit.

HTTP Features (HTTP/1.1)#

Advantages and Disadvantages of HTTP#

The advantages of HTTP are "simple, flexible, easy to extend, widely used, and cross-platform."

The disadvantages of HTTP are "stateless, plaintext transmission," (plaintext transmission + inability to verify message integrity) -> "insecure."

HTTP Performance#

The HTTP protocol is based on TCP/IP and uses a "request-response" communication model:

Persistent connections: As long as neither end explicitly requests to disconnect, the TCP connection state is maintained, reducing the overhead caused by repeatedly establishing and disconnecting TCP connections, thus alleviating the server's load.
Pipelined network transmission: In the same TCP connection, after the client sends a request, it can send the next request without waiting for a response, reducing overall response time. However, the server must send responses to these pipelined requests in the order they were received.
Head-of-line blocking: If the server takes a long time to process request A, subsequent requests will be blocked, which is called "head-of-line blocking." HTTP/1.1 pipelining solves the head-of-line blocking for requests but does not solve the head-of-line blocking for responses.

The performance of HTTP/1.1 is generally average; subsequent HTTP/2 and HTTP/3 are aimed at optimizing HTTP performance.

HTTP vs HTTPS#

When establishing a connection, HTTPS includes an additional TLS handshake process compared to HTTP;
During content transmission, HTTPS encrypts the data, usually using symmetric encryption;

Differences Between HTTP and HTTPS#

Security
Connection establishment
Default port
URL prefix
Certificates

Security Issues Addressed by HTTPS#

HTTPS adds the SSL/TLS protocol between HTTP and TCP layers.

Eavesdropping risk -> Information encryption -> Hybrid encryption
Tampering risk -> Verification mechanism -> Hash algorithm ~~+ Digital signature~~
- Hash algorithms can ensure message integrity;
- ~~Digital signatures can ensure the reliability of the message source (confirming that the message was sent by the holder of the private key);~~
Impersonation risk -> Identity certificate -> Embedding the server's public key in the digital certificate

CA signs the digital certificate to ensure that the certificate is trustworthy. (Certificate trust chain issue)

~~Essentially: the issue of the client trusting the server~~

Establishing HTTPS Connections#

Basic process of the SSL/TLS protocol:

The client requests and verifies the server's public key.
Both parties negotiate to produce a "session key."
Both parties use the "session key" for encrypted communication.

The first two steps constitute the SSL/TLS establishment process, which is the TLS handshake phase, involving four communications (SSL/TLS 1.2).

Using different key exchange algorithms results in different TLS handshake processes; currently, two commonly used key exchange algorithms are RSA and ECDHE.

ClientHello, initiated by the client to request encrypted communication

Client random number (Client Random) ...
ServerHello, after receiving the client's request, the server responds to the client

Server random number (Server Random) + server's digital certificate ...
Client responds

Public key encrypted random number pre-master key + client handshake completion notification ...
Server's final response

Server handshake completion notification + handshake summary

At this point, the entire TLS handshake phase ends, and the client and server enter encrypted communication, using the ordinary HTTP protocol, but with the content encrypted using the "session key."

HTTPS Ensures Data Integrity#

TLS is implemented in two layers: handshake protocol and record protocol:

The TLS handshake protocol is the process of the four-way handshake, responsible for negotiating encryption algorithms and generating symmetric keys;
The TLS record protocol is responsible for protecting application data and verifying its integrity and origin, using the record protocol to encrypt HTTP data;

The TLS record protocol mainly handles the compression, encryption, and authentication of messages (HTTP data):

It splits messages into multiple shorter segments and compresses each segment separately.
It adds a message authentication code (MAC, obtained through a hash algorithm) to the compressed segments to ensure data integrity and authentication.
It encrypts the compressed message segments + message authentication code using the symmetric key.
The encrypted data, along with the data type, version number, and compressed length, forms the final message data.

After the record protocol is completed, the final message data is passed to the transport control protocol (TCP) layer for transmission.

Evolution of HTTP#

HTTP/1.1 vs. HTTP/1.0#

Persistent connections
Support for pipelined network transmission, allowing subsequent requests to be sent without waiting for a response

HTTP/2.0 vs. HTTP/1.1#

HTTP/2.0 is based on HTTPS, offering higher security
Header compression using the HPACK algorithm
Binary format
Concurrent transmission, Stream, multiple requests reuse a single TCP connection
Server push

HTTP/2.0 still has head-of-line blocking issues, occurring at the TCP layer; only when TCP data is continuous can the application layer read data from the kernel. Once packet loss occurs, all HTTP requests will be blocked.

HTTP/3#

HTTP/3 uses the UDP protocol at the lower layer to solve the head-of-line blocking problem.

The UDP-based QUIC protocol can achieve reliability similar to TCP; QUIC has the following characteristics:

No head-of-line blocking: When a packet is lost in a stream, only that stream is blocked, not affecting other streams; multiple Streams are independent of each other.
Faster connection establishment: QUIC includes TLS internally, allowing connection establishment and key negotiation to be completed in just 1 RTT.
Connection migration: The QUIC protocol does not "bind" connections using a four-tuple but uses a connection ID to mark the two endpoints of communication.
Security: In HTTP/2.0, TLS is used to encrypt and authenticate the entire HTTP session, including all HTTP headers and data payloads. TLS operates above the TCP layer, encrypting application layer data transmitted over TCP connections, but does not encrypt the TCP header or TLS record layer header, leaving the TCP header vulnerable to tampering by attackers. In contrast, HTTP/3.0's QUIC encrypts and authenticates the entire data packet (including headers and body), ensuring security.

Thus, QUIC is a pseudo TCP + TLS + HTTP/2 multiplexing protocol built on UDP.

TCP_Interview#

TCP Header Format#

The TCP header occupies 20 bytes when no options are used:

Source port number (16 bits) + Destination port number (16 bits)
Sequence number (32 bits): solves the out-of-order problem
Acknowledgment number (32 bits): solves the packet loss problem
Header length (4 bits) + Reserved (6 bits) + Control bits (6 bits) + Window size (16 bits)
Checksum (16 bits) + Urgent pointer (16 bits)

The Significance of TCP#

The IP protocol at the network layer does not guarantee reliable delivery; if reliable delivery of network packets is required, it must be handled by the TCP protocol at the transport layer.

This is because the TCP protocol is a reliable data transmission service that operates at the transport layer, ensuring that received network packets are undamaged, uninterrupted, non-redundant, and in order.

What is TCP#

TCP is a connection-oriented, reliable, byte-stream-based transport layer communication protocol.

What is a TCP Connection#

Connection: A combination of certain state information used to ensure reliability and flow control maintenance, including socket, sequence number, and window size.

Establishing a TCP connection requires the client and server to reach a consensus on the following information:

Socket: TCP four-tuple
Sequence number: used to solve the out-of-order problem
Window size: used for flow control

Differences Between TCP and UDP#

The UDP header is fixed at 8 bytes:

Source port number (16 bits) + Destination port number (16 bits)
Packet length (16 bits) + Checksum (16 bits)

UDP only uses the connectionless communication service provided by IP.

The differences between TCP and UDP are as follows (remembering the logic):

Connection: TCP is connection-oriented, while UDP is connectionless.
Service object: TCP is a point-to-point service, while UDP can be one-to-many.
Reliability: TCP reliably delivers data, while UDP makes a best-effort delivery without guaranteeing reliability.
TCP provides congestion control and flow control mechanisms to ensure data transmission safety; UDP does not.
Header overhead: TCP header is 20 bytes when no options are used, while UDP header is fixed at 8 bytes.
Transmission method: TCP is byte-stream-based, while UDP sends data in packets with boundaries.
Fragmentation: TCP data larger than MSS will be fragmented at the transport layer, while UDP only uses the fragmentation of the network layer IP protocol (greater than MTU).

TCP application scenarios:

FTP file transfer
HTTP/HTTPS

UDP application scenarios:

Multimedia communication
Broadcast communication
Communication with smaller packet sizes: such as DNS, SNMP, etc.

TCP Connection Establishment#

TCP establishes connections through a three-way handshake.

Why Three-Way Handshake Instead of Two or Four?#

Prevents the initialization of duplicate historical connections.

"Old SYN packets" are called historical connections; the main reason TCP uses a three-way handshake to establish connections is to prevent the initialization of "historical connections."
Synchronizes the initial sequence numbers of both parties.

When the client sends a SYN packet with the "initial sequence number," the server must respond with an ACK acknowledgment packet, indicating that the client's SYN packet has been successfully received. When the server sends the "initial sequence number" to the client, it also requires an acknowledgment from the client, ensuring that both parties' initial sequence numbers can be reliably synchronized.
Avoids resource waste.

If there were only "two-way handshake," and the client's SYN packet gets blocked in the network, causing multiple SYN packets to be sent, the server would establish multiple redundant invalid connections upon receiving the request, leading to unnecessary resource waste.

Why Are the Initial Sequence Numbers Different When Establishing a TCP Connection?#

To prevent historical packets from being incorrectly received by connections with the same four-tuple (main aspect).
To prevent hackers from forging TCP packets with the same sequence number.

The algorithm for generating the Initial Sequence Number (ISN) is: ISN = M + F(localhost, localport, remotehost, remoteport).

M is a timer that increments every 4 microseconds.
F is a hash algorithm that generates a random value based on the source IP, destination IP, source port, and destination port. The hash algorithm must not be easily predictable from the outside; using the MD5 algorithm is a good choice.

The random number is incremented based on the clock timer, making it nearly impossible to generate the same initial sequence number.

About SYN Attacks#

Assuming an attacker forges SYN packets from different IP addresses in a short time, the server enters the SYN_RCVD state for each received SYN packet. However, the ACK + SYN packets sent by the server cannot receive acknowledgments from unknown IP hosts, eventually filling the server's half-connection queue, preventing the server from serving normal users.

The most direct manifestation of a SYN attack is that it fills the TCP half-connection queue, causing subsequent SYN packets to be discarded when the queue is full, preventing the client from establishing a connection with the server.

To avoid SYN attacks, the following four methods can be employed:

Increase netdev_max_backlog;
Increase the TCP half-connection queue;
Enable tcp_syncookies;
Reduce the number of SYN+ACK retransmissions.

TCP Connection Termination#

TCP disconnects connections through a four-way handshake, requiring one FIN and one ACK for each direction.

About TIME_WAIT State#

The TIME_WAIT state is necessary for two main reasons:

To prevent data from historical connections from being incorrectly received by subsequent connections with the same four-tuple;

The TIME_WAIT state lasts for 2MSL, which is sufficient to allow data packets from both directions to be discarded, ensuring that packets from the original connection naturally disappear from the network, and any reappearing packets are from newly established connections. (MSL is Maximum Segment Lifetime.)
To ensure that the "passively closed connection" can be properly closed;

The purpose of TIME_WAIT is to wait long enough to ensure that the last ACK can be received by the passive closing party, thus helping it to close properly.

If the client does not enter the TIME_WAIT state and directly goes to the CLOSE state after sending the last ACK packet, if that ACK packet is lost, the server will retransmit the FIN packet. At this point, the client has already entered the closed state, and upon receiving the server's retransmitted FIN packet, it will respond with a RST packet.

To prevent this situation, the client must wait long enough to ensure that the server receives the ACK. If the server does not receive the ACK, it will trigger the TCP retransmission mechanism, and the server will resend a FIN packet, resulting in a back-and-forth exchange that takes exactly two MSLs.

When the client receives the server's retransmitted FIN packet, the waiting time in the TIME_WAIT state will reset to 2MSL.

Excessive TIME_WAIT states can have two main harms:

First, they occupy system resources, such as file descriptors, memory resources, CPU resources, thread resources, etc.;
Second, they occupy port resources, which are limited; generally, the range of ports that can be opened is 32768–61000, and this range can also be specified through the net.ipv4.ip_local_port_range parameter.

TIME_WAIT is our friend; it is beneficial to us. Do not try to avoid this state; instead, understand it.

If the server wants to avoid excessive TIME_WAIT states, it should never actively close connections, allowing clients to do so, letting the distributed clients bear the TIME_WAIT.

If the server experiences a large number of TIME_WAIT states for TCP connections, it indicates that the server has actively closed many TCP connections, which can occur in the following scenarios:

The first scenario: HTTP does not use persistent connections (Keep-Alive).
The second scenario: HTTP persistent connections have timed out.
The third scenario: The number of requests for HTTP persistent connections has reached the limit.

TCP Keep-Alive Mechanism#

A time period is defined, during which if there are no connection-related activities, the TCP keep-alive mechanism will begin to take effect, sending a probe packet at regular intervals. This probe packet contains very little data; if several consecutive probe packets do not receive a response, the current TCP connection is considered dead, and the system kernel will notify the upper application.

The detection time for the TCP keep-alive mechanism is somewhat long; we can implement a heartbeat mechanism at the application layer.

Socket Programming#

For TCP socket programming:

The server and client initialize the socket, obtaining a file descriptor;
The server calls bind, binding the socket to the specified IP address and port;
The server calls listen to start listening;
The server calls accept, waiting for client connections;
The client calls connect, initiating a connection request to the server's address and port;
The server's accept returns the file descriptor for the socket used for transmission;
The client calls write to send data; the server calls read to read data;
When the client disconnects, it calls close, and the server, upon reading data, will read EOF. After processing the data, the server calls close, indicating that the connection is closed.

When the server calls accept, a successful connection will return a socket for the completed connection, which is used for data transmission. There are "two" sockets: one is the listening socket, and the other is the completed connection socket.

Once the connection is successfully established, both parties begin to read and write data using the read and write functions, just like writing to a file stream.

IP_Base#

IP is responsible for communication transmission between two networks that are "not directly connected";

MAC serves to facilitate communication between two devices that are "directly connected";

IP Address Classification#

Classified addresses: Class A, Class B, Class C, Class D, Class E.

Classless address CIDR: A 32-bit IP address is divided into two parts, with the front being the network number and the back being the host number.

Classless Inter-Domain Routing (CIDR)

Subnet mask, which means masking the host number, leaving the network number. By performing a bitwise AND operation between the subnet mask and the IP address, the network number can be obtained.

The subnet mask can be used to divide the network number and host number; in fact, the subnet mask also serves the purpose of subnetting.

Subnetting essentially divides the host address into two parts: subnet network address and subnet host address.

IP Address and Routing Control#

The network address portion of an IP address is used for routing control.

The routing control table records the network address and the address to which it should be sent next. Each host and router has its own routing control table.

When sending an IP packet, the target address in the IP packet header must first be determined, and then the routing control table is consulted to find records with the same network address. Based on that record, the IP packet is forwarded to the appropriate next router. If there are multiple records with the same network address in the routing control table, the one with the longest matching prefix is selected.

The loopback address is a default address used for network communication between programs on the same computer.

Computers use a special IP address 127.0.0.1 as the loopback address. A hostname called localhost has the same meaning as this address. When using this IP or hostname, the data packets do not flow to the network.

IP Fragmentation and Reassembly#

The maximum transmission unit (MTU) varies for different data links, such as FDDI data link MTU 4352, Ethernet MTU is 1500 bytes, etc.

The reason for the different MTUs for each data link is that each type of data link serves different purposes. Different purposes allow for different MTUs.

When the size of an IP packet exceeds the MTU, the IP packet will be fragmented.

Once fragmented, the reassembly of the IP datagram can only be performed by the destination host; routers do not perform reassembly.

In fragmented transmission, if any fragment is lost, the entire IP datagram becomes invalid. Therefore, TCP introduces MSS, which means fragmentation occurs at the TCP layer rather than the IP layer. For UDP, we should avoid sending a datagram larger than the MTU.

Basic Understanding of IPv6#

IPv4 addresses are 32 bits long (4 bytes), represented in dotted-decimal format with each 8 bits as a group.

IPv6 addresses are 128 bits long (16 bytes), represented with each 16 bits as a group, separated by colons ":".

If there are consecutive zeros, they can be omitted and replaced with two colons "::". However, only one occurrence of two consecutive colons is allowed in an IP address.

IPv6 not only increases the number of assignable addresses but also has many highlights.

IPv6 can be automatically configured, allowing for automatic IP address assignment even without a DHCP server, making it plug-and-play.
The header length of IPv6 is fixed at 40 bytes, removing the header checksum, simplifying the header structure, reducing the router's load, and greatly improving transmission performance.
IPv6 has features to counteract IP address spoofing and prevent line eavesdropping, significantly enhancing security.
...

Improvements in the IPv6 header compared to IPv4:

The header checksum field has been removed. Since checks are performed at both the data link layer and transport layer, IPv6 directly eliminates the IP checksum.
Fields related to fragmentation/reassembly have been removed. Fragmentation and reassembly are time-consuming processes; IPv6 does not allow fragmentation and reassembly at intermediate routers; this operation can only occur at the source and destination hosts, greatly improving the forwarding speed of routers.
The options field has been removed. The options field is no longer part of the standard IP header but may appear at a location indicated by the "next header" in the IPv6 header. Removing the options field makes the IPv6 header a fixed length of 40 bytes.

DNS Domain Name Resolution#

DNS can automatically convert domain names into specific IP addresses.

The hierarchical relationship of domain names resembles a tree structure:

Root DNS server
Top-level domain DNS server (com)
Authoritative DNS server (server.com)

The browser first checks its cache; if not found, it queries the operating system's cache. If still not found, it checks the local domain name resolution file hosts. If still not found, it queries the DNS server, and the process is as follows:

The client first sends a DNS request asking for the IP of www.server.com and sends it to the local DNS server (the DNS server address specified in the client's TCP/IP settings).
If the local DNS server finds the IP address for www.server.com in its cache, it directly returns it. If not, the local DNS will ask its root DNS server: "Boss, can you tell me the IP address for www.server.com?". The root DNS server is the highest level and does not directly resolve domain names but can point the way.
The root DNS server receives the request from the local DNS and sees that the suffix is .com, saying: "www.server.com is managed by the .com zone; I will give you the .com top-level domain server address, you can ask it."
The local DNS receives the address of the top-level domain server and sends a request asking, "Boss, can you tell me the IP address for www.server.com?"
The top-level domain server says: "I will give you the address of the authoritative DNS server responsible for www.server.com; you can ask it."
The local DNS then turns to the authoritative DNS server: "Boss, what is the IP for www.server.com?" The authoritative DNS server for server.com is the original source of the domain name resolution result. It is called authoritative because it is the master of its domain.
After querying, the authoritative DNS server tells the local DNS the corresponding IP address X.X.X.X.
The local DNS then returns the IP address to the client, allowing the client to establish a connection with the target.

The process of DNS domain name resolution is similar to asking for directions in daily life, only pointing the way, not leading the way.

ARP Address Resolution Protocol#

ARP is a network transmission protocol that resolves network layer addresses to find data link layer addresses.

ARP determines MAC addresses using ARP requests and ARP responses.

The host sends an ARP request via broadcast, which includes the IP address of the host whose MAC address is desired.
When all devices on the same link receive the ARP request, they will unpack the contents of the ARP request packet. If the target IP address in the ARP request matches their own IP address, that device will include its MAC address in the ARP response packet sent back to the host.

Operating systems typically cache the MAC addresses obtained through ARP for future direct access.

The ARP protocol seeks a MAC address based on a known IP address, while the RARP protocol does the opposite, seeking an IP address based on a known MAC address.

Additionally, when the sending host and destination host are not on the same local area network, even if the MAC address is known, they cannot communicate directly and must go through a router for IP layer forwarding, as the router isolates the link layer of the local area network (unless explicit forwarding at the network layer is performed, the router will not automatically forward Ethernet frames from one local area network to another or to the external network; if it could, imagine how terrifying it would be, as invalid broadcast frames could flood the entire network and paralyze it, which is one of the basic functions of a router: to isolate networks). Therefore, in this case, the sending host will use a gateway IP address as the destination IP address (this is determined at the IP layer), and the MAC address obtained through the ARP protocol will not be the true MAC address of the destination host, but rather the MAC address of a router that can reach outside the local area network. Subsequently, all frames sent by the sending host to the destination host will be sent to that router, which will forward them outward. This situation is referred to as delegated ARP or ARP Proxy.

DHCP Dynamic Host Configuration Protocol#

DHCP is a communication protocol that enables network administrators to centrally manage and automatically allocate IP network addresses.

The DHCP client process listens on port 68, while the DHCP server process listens on port 67.

The client first initiates a DHCP discovery message (DHCP DISCOVER) in an IP datagram. Since the client does not have an IP address and does not know the address of the DHCP server, it uses UDP broadcast communication, with the broadcast destination address being 255.255.255.255 (port 67) and using 0.0.0.0 (port 68) as the source IP address. The DHCP client passes this IP datagram to the link layer, which then broadcasts the frame to all devices on the network.
Upon receiving the DHCP discovery message, the DHCP server responds to the client with a DHCP offer message (DHCP OFFER). This message also uses the IP broadcast address 255.255.255.255 and carries information about the IP address, subnet mask, default gateway, DNS server, and IP address lease duration that the server is offering.
After the client receives one or more DHCP offer messages from servers, it selects one server and sends a DHCP request message (DHCP REQUEST) in response, echoing the configured parameters.
Finally, the server responds to the DHCP request message with a DHCP ACK message, confirming the requested parameters.

Once the client receives the DHCP ACK, the interaction is complete, and the client can use the IP address allocated by the DHCP server during the lease period.

If the leased DHCP IP address is about to expire, the client will send a DHCP request message to the server:

If the server agrees to continue the lease, it will respond with a DHCP ACK message, and the client will extend the lease.
If the server does not agree to continue the lease, it will respond with a DHCP NACK message, and the client must stop using the leased IP address.

It can be observed that the entire DHCP interaction uses UDP broadcast communication.

With the DHCP relay agent, IP address allocation across different subnets can also be centrally managed by a single DHCP server.

The DHCP client sends a DHCP request packet to the DHCP relay agent, which, upon receiving this broadcast packet, forwards it to the DHCP server in unicast form.
The server then responds to the DHCP relay agent, which broadcasts the response back to the DHCP client.

Thus, a DHCP server can achieve unified allocation and management of IP addresses even if it is not on the same link.

NAT Network Address Translation#

Network Address Translation (NAT) is a technique that rewrites the source or destination IP address or port of IP packets as they pass through a router or firewall. This technique is commonly used in private networks with multiple hosts that access the internet through a single public IP address.

In simple terms, NAT translates the private IP addresses of hosts within a company, home, or classroom to a public IP address for external communication.

It can also translate the combination of IP address + port number. This way, a single global IP address can be used, and this translation technique is called Network Address and Port Translation (NAPT).

The NAPT router maintains a translation table that correctly translates the combination of addresses and ports.

Since both NAT and NAPT rely on their own translation tables, the following issues may arise:

External hosts cannot actively connect to NAT internal servers because the NAPT translation table does not have a translation record.
The generation of translation tables and translation operations incur performance overhead.
If the NAT router restarts during communication, all TCP connections will be reset.

The solutions mainly include two approaches.

The first is to switch to IPv6.
NAT traversal technology.

In NAT traversal technology, applications behind NAT devices take an active role; they are aware that the NAT device will modify their outbound packets, so they cooperate with the NAT device's operations, actively establishing mappings instead of relying on the NAT device to do so.

The client actively obtains a public IP address from the NAT device, then establishes port mapping entries, and uses these entries for external communication, eliminating the need for the NAT device to perform translations.

ICMP#

ICMP stands for Internet Control Message Protocol.

ICMP mainly functions to confirm whether IP packets successfully reach the target address, report reasons for IP packet discards during transmission, and improve network settings.

ICMP can be roughly divided into two categories:

One type is diagnostic query messages, known as "query message types."
The other type is error messages that notify of error reasons, known as "error message types."

IGMP#

IGMP is the Internet Group Management Protocol, operating between hosts (multicast members) and the last-hop router.

IGMP messages request routers to join and leave multicast groups. By default, routers do not forward multicast packets to connected hosts unless hosts join multicast groups via IGMP; when a host requests to join a multicast group, the router records this in the IGMP router table, and subsequently forwards multicast packets to the corresponding hosts.
IGMP messages are encapsulated in IP, with the IP header's protocol number set to 2, and the TTL field value is usually 1, as IGMP operates between hosts and the connecting router.

Multicast addresses are not used for machine IP addresses, as multicast addresses do not have network and host numbers, so they are unrelated to DHCP. Multicast addresses are generally used for the UDP protocol; when a machine sends UDP multicast data, the target address is filled with the multicast address, allowing all machines within the multicast group to receive the data packets.

Joining and leaving multicast groups is implemented through a socket interface, and the host IP does not need to change.

Others#

OSPF (Open Shortest Path First): An interior gateway protocol (IGP) widely used as a dynamic routing protocol based on link-state algorithms, considering factors like link bandwidth and latency to select the best path.
RIP (Routing Information Protocol): An interior gateway protocol (IGP) that is also a dynamic routing protocol based on distance vector algorithms, using fixed hop counts as a metric to select the path with the fewest hops as the best path.
BGP (Border Gateway Protocol): A routing protocol used to exchange network layer reachability information (NLRI) between routing domains, offering high flexibility and scalability.
